smart LED lighting fixture
technology
Revolutionizing Illumination with Intelligent LED Technology
HLTEC’s Smart LED Lighting Fixtures bring cutting-edge intelligence to lighting solutions, combining energy efficiency, advanced controls, and modern design. Equipped with IoT-enabled features, these fixtures offer remote monitoring, automated dimming, and adaptive brightness based on environmental conditions. Perfect for urban, industrial, and smart city applications, our Smart LED Lighting Fixtures deliver sustainable performance, reduced energy consumption, and seamless integration into modern infrastructure projects.
LED module
Smart LED
Streetlight & Security Light fixture Dedicated module development completed
Color Spectrum
| Model | BS-CM80SH |
| Power | 25W↓ |
| Luminous Efficiency | 130ml/W↑ |
| Color Temperature | 2,700K ~ 6,500K |
| Color Rendering | 80↑ |
IoT converter (dimming / color control, waterproof)
| division | Contents |
| Input Power | 100~240 VAC, 50~60Hz |
| Power Line | Broad band PLC |
| Output Power | 50W ~ 125W |
| Sensor Power | Microwave, PIR Sensor |
| Sensor Type | UART / IO Signal Detection |
| Product Spe | 220*50*40mm(125W) / 118*62*40mm(50W), IP 66 |
| Note | Dimming/coloring(brightness/color temperature) control using broadband power line communications AC power monitoring(voltage, current, power, etc.) DC power monitoring(voltage, current) Error detection function |
- Simplified structure
dimming modem + converter + sensor controller - Easy installation and construction
Reduced installation area, shortened construction time - Improved maintenance efficiency
Real-time status monitoring
Operation information storage statistics
gateway
LED Lighting Gateway [Manufacturer:Risantech]
Identification Number: 23467369 / 2,300,000 won
- Individual control, group control with streetlight dimming lighting control device and power line communication
- ON/OFF control function
- Individual, group, and overall control and schedule control of lighting fixtures possible
Light Detection Sensor [Manufacturer: isantech]
Identification Number: 23865255 / 3,000,000 won
- Measure the illuminance value and apply it to the illuminance control device, gateway, and lighting control device Can be transmitted to automatically control lighting devices, etc
- Change dimming function according to external brightness according to season/time
Ex) 50% Brightness – 100% Change
0 → 100% reference power changeable
Environmental (fog) sensor
- Non-registered products of Public Procurement Service (subsidized contract progress)
- Color change according to weather and humidity (color temperature can be changed based on 2,700 to 6,500K) Ex) Color temperature 6,500K on a sunny day When cloudy or foggy, color temperature 2,700K
